ELECTRICAL TRIPODE TURNSTILE
Description
The Ww-882-316 series of pivot barriers are designed to control pedestrians
entering or existing restricted areas, usually under surveillance, in
low security situations. The rotation is 3 x 1200. This model of a tri-arm
design can be used in two directional control applications with high
usage of pedestrian traffic such as:
¡ESubway
platform
¡ELibraries
¡EAirports
¡ESport
stadiums
¡EFactories
¡EMuseums
¡EAmusement
Park
Housing
The weather - proof housing
in stainless sheet of 1.5mm thickness.
Technology
The
electric bolt locking mechanism is quiet & utilises an encoder for
position sensing. It is to ensure smooth rotation & 3 x 1200
indexing, as well as hydraulic braking & positioning of the turnstile
bars.
Features
A
special feature is the manually free releasing lock for the passageway
can be used as an emergency exit.
¡EEntry and exit controlled
¡EEntry controlled, exit permanently free
¡EExit controlled ,entry permanently free.
¡EEntry/Exit access/denied indicators on top cover.
The controller provides interfacing from associated access control devices to activate the bi-directional release mechanism. All inputs & outputs are opto-isolated & incorporate solid state available with reset key switches if required. All units can be provided with built-in or externally fixed badge readers or keypads. Operation of the systems may be stand alone or on-line with a connection to a central computer for time & attendance recording & other data acquisitions.
